A-A-55126B
TABLE VII Test methods (Continued)
9/ 10/ ASTM D 5169
After Autoclaving
Table I
(Type IV only )
Peel strength 5/ 7/
After 3 launderings
Table I
AATCC 61, Test 3A, ASTM D 5170
After 1 dry cleaning 8/
Table I
AATCC 132, ASTM D 5170
Stitch tear strength
Table I
ASTM D 2261, Option 1 11/
Thickness
Table II
ASTM D 1777, Option 5 12/
Length Dimensional Stability
Table II
AATCC 135 Option 3, V, Aiii
Autoclave(Thermal) Length
Shrinkage(Type IV only) 9/
Table II
9/ 10/
Colorfastness
Light (40 hrs or 170 KJ)
Table III
AATCC 16, Option 1or 3
Laundering 13/
Table III
Universal Camouflage Shades
Table III
AATCC 61, Option 3A
(5 Cycles)
Table III
AATCC 61, Option 2A
All Other Colors (3 cycles)
Table III
AATCC 132
Dry Cleaning (1 cycle) 8/
Crocking
Table III
AATCC 8
Thermal Stability
3.4
NFPA 1975
(Class 2 only)
3.6
3.6.1
Spectral Reflectance
3.10
3.10.1 3.10.2.1.2
Fray Resistance
1/ Test specimen shall be full width and 3 feet in length.
2/ When splices are tested for breaking strength, the splice shall be centered between the jaws.
3/ Test with hook side up.
4/ Stiffness (bending moment) shall be conducted in accordance with ASTM D 747 except as
follows:
a. Unless otherwise specified, the testing conditions shall be in accordance with ASTM
D 1776.
b. The test specimen shall be a rectangle of cloth of dimensions two (2) by one (1) inches
with the long dimension parallel to the fabric direction under test, warp or filling, as
applicable.
c. The load scale reading shall be recorded only at the specimen angular deflection of 60
degrees.
d. The stiffness is the bending moment of specimen at a deflection angle of 60 degrees and
shall be calculated to three significant figures as follows:
Bending moment, inch -lb. = Load scale reading X moment weight*
100
* Testing machine of Tinius Olsen Testing Machine Co.
11
